產品名稱：VICOR 產品介紹：
|
詳細介紹
Vicor電源模塊
Vicor詳細產品資料請點擊：http://www.www.3fzread.cn/vicor.html
 |
 |
 |
 |
 |
 |
 |
 |
 |
|
Industry Standard Eighth and Quarter Bricks High Efficiency: >98% High Density: 255 W/in² |
High Efficiency and High Power Density | High Efficiency and Thermally Enhanced | High Efficiency and High Power Density |
Very High Power Density |
High Efficiency and Thermally Enhanced | High Current Models | High Power Broad Vout Trim Range |
Broad Selection and Current Source Module |
|
|
|
|||||||
|
|
||||||||
|
38 – 55 Vdc 36 – 60 Vdc |
18 – 75 Vdc Four Input Ranges |
18 – 75 Vdc Four Input Ranges |
38 – 55 Vdc / 330 – 400 Vdc Four Input Ranges |
36 - 75 18 - 36 41 - 57 Vdc |
38 – 55 Vdc / 330 – 400 Vdc Four Input Ranges |
36 – 75 Vdc One Input Range |
9 – 425 Vdc Eight Input Ranges |
10 – 400 Vdc Twelve Input Ranges |
|
4:1 and 5:1 fixed ratio 12 and 9.6 V at 48 Vin |
1.19 – 55 Vdc | 0.82 – 55 Vdc | 1.2 – 55 Vdc |
3.3 Vdc 12 Vdc 18 Vdc |
1 – 48 V | 1 – 48 Vdc | 2 – 54 Vdc | 2 – 95 Vdc |
| 300 – 850 W | 120 – 500 W | 120 – 320 W | 120 – 325 W | 10 – 60 W | 135 – 325 W | 100 – 220 W | 50 – 600 W | 25 – 200 W |
|
Eighth Brick, Open Frame 2.30" x 0.9" x 0.38" (58,4 x 22,9 x 9,53 mm) Quarter Brick, Open Frame 2.30" x 1.45" x 0.41" (58,4 x 36,8 x 10,5 mm) |
Full Chip 1.28" x 0.87" x 0.265" (32,5 x 22,0 x 6,73 mm) Half Chip 0.87" x 0.65" x 0.265" (22,0 x 16,5 x 6,73 mm) |
Full Size Flanged 1.91" x 1.09" x 0.37" (48,6 x 27,7 x 9,5 mm) |
Full Chip 1.28" x 0.87" x 0.265" (32,5 x 22,0 x 6,73 mm) Half Chip 0.87" x 0.65" x 0.265" (22,0 x 16,5 x 6,73 mm) |
Power System in Package (PSIP) 0.87" x 0.65" x 0.26" (22,0 x 16,5 x 6,73 mm) |
Full Size Flanged 1.91" x 1.09" x 0.37" (48,6 x 27,7 x 9,5 mm) |
Flanged baseplate (Height above board) 2.19" x 1.91" x 0.37" (55,7 x 48,6 x 9,5 mm) |
Maxi (Full Brick) 4.6" x 2.2" x 0.5’’ (117 x 55,9 mm) Mini (1/2 Brick) 2.28" x 2.2" x 0.5’’ (57,9 x 55,9 mm) Micro (1/4 Brick) 2.28" x 1.45" x 0.5’’ (57,9 x 36,8 mm) |
VI-200 (Full Brick): 4.6" x 2.4" x 0.5" (116,9 x 61,0 x 12,7 mm) VI-J00 (Half Brick): 2.28" x 2.4" x 0.5" (57,9 x 61,0 x 12,7 mm) |
| Through Hole |
SMT or Through Hole Half Chip only SMT |
Through Hole |
SMT or Through Hole Half Chip only SMT |
SMT | Through Hole | Through Hole | Through Hole | Through Hole |
